威爾信帕金斯柴油發電機超速報警的原因與解決方法

Engine overspeed
perkins發動機超速
Test 36
試驗36
Event
事件
Engine overspeed Warning
發動機超速警告
Engine overspeed Action Alert
發動機超速行動警報
Engine overspeed Shutdown
發動機超速停機
Code
代碼
E362-1
e362-1
E362-2
e362-2
E362-3
e362-3
Probable root causes
可能的根本原因
Engine overspeed set point
發動機超速設置點
Incorrect speed setting
不正確的速度設置
Driven equipment motoring
汽車驅動設備
Slow governor response
州長響應慢
Perform the following tests
執行下列測試
1 Engine overspeed set point
1發動機超速設置點
Check that the engine overspeed set point is correctly programmed. Only the Warning level can be changed
檢查發動機超速設置點的正確程序。只有警戒級別可以改變
using the electronic service tool, The Action Alert and Shutdown lev els are factory set and cannot be changed.
使用電子服務的工具，行動警報和關閉水平的出廠設置和不能改變的。
2 Check analogue, PWM or remote manual throttle settings.
2檢查模擬，脈寬調制或遠程手動油門設置。
3 Driven equipment motoring
3驅動裝置的汽車
Determine if the driven equipment has additional energy inputs that could drive the engine beyond it’s rated
確定驅動設備是否具有額外的能量輸入，可以驅動發動機超出額定功率
rev/min.
轉/分。
4 Slow governor response
4慢調速器響應
Watch the engine response to worst case step loading and step unloading on the TIPSS-EST graphing screen.
看最壞的情況下，分級加載和卸載的步驟tipss-est圖形屏幕發動機響應。
Refer to "Governor gain parameters" on page 33 if the engine speed undershoot or engine speed overshoot
參見“州長增益參數”頁33如果發動機速度下沖或發動機轉速超調
is excessive.
過度。 珀金斯發電機組ECU,卡特柴油機 ECU,沃爾沃柴油機 ECU,珀金斯柴油機 ECU,catECM發動機模塊,沃爾沃ECM柴油發動機模塊,珀金斯ECM發動機模塊
